⚫Standard version maximum grinding length: 380mm (Customizable up to 1000mm)High-strength version maximum grinding length: 400mm (Customizable according to customer needs)

⚫Spindle drive power: Star-delta asynchronous motor 7.5-18.5kw(Optional YE4 energy-saving motor or permanent magnet synchronous motor)

⚫Grinding wheeldiameter:260mm-450mm

⚫Mechanical transmission method-X-axis: P3 Heavy load roller linear guide (optional cvlindrical linear quide)/ C3 or P4 ground ball screw.Y-axis: P3 Heavy load roller linear guide (optional cylindrical linear guide) / C3 or P4 ground ball screw-Z-axis: P3 Heavy load roller linear guide (optional cylindrical linear guide)/ C3 or P4 ground ball screwA-axis:Worm gear structure(Optional RV reducer)

⚫Power system:Bus absolute value motor

⚫Lubrication system:Centralized central lubrication pump

⚫Spindle:A2-6 High-strength precision spindleSoindle with side clearance preload precision bearinas, the design circular line speed can reach 30m/s Horizontal spindle with barrel grinding wheel

⚫CNC system:WEIHONG NK280B system

⚫We can provide a weath of customization services to meet the diverse processing needs of our customers.

⚫Optional accessories: lnverter (VFD), multi-stage purification water tank, grinding wheel compensation sensor,X-axis length customization, A-axis drive method, and mist collector, etc.
